Description
The 60SH16H is a single-strand roller chain sprocket with 16 teeth, a 3/4-inch pitch, and an SH QD (Quick Disconnect) bushing bore. It is specifically engineered to operate with standard ANSI size 60 roller chain and features a robust, one-piece forged design with hardened teeth to maximize service life and reduce chain wear.
Key Specs
- Chain Size: ANSI 60
- Teeth Count: 16
- Pitch Size: 3/4 inch
- Pitch Diameter: 3.844 inches
- Outside Diameter: 4.220 inches
- Bushing Type: SH Quick Detachable (QD)
- Maximum Bore Capacity: 1-5/8 inches (with appropriate SH bushing)
Design and Use
- Hardened Teeth: Heat-treated teeth resist wear, which is highly recommended by manufacturers like Martin Sprocket for smaller sprockets running at higher drive ratios or speeds.
- QD Style Component: Designed as a "rim only" flanged configuration that tightly bolts to an interchangeable SH bushing using three mounting screws.
- Corrosion Resistance: Most models, such as those from Tritan and Surplus Center, feature a black oxide finish to protect against environmental degradation.
- Power Transfer: Commonly utilized in heavy-duty machinery, agricultural equipment, and high-torque conveyor systems.
