Description
The 60SK30H is a single-strand roller chain sprocket with 30 teeth, a 3/4-inch pitch, and an SK QD (Quick Disconnect) bushed bore. Engineered to run with standard ANSI size 60 roller chain, this sprocket features induction-hardened teeth to minimize wear and prolong component life under continuous loads.
Key Specs
- Chain Size: ANSI 60
- Teeth Count: 30
- Pitch Size: 3/4 inch (0.750")
- Pitch Diameter: 7.174 inches
- Outside Diameter: 7.590 inches
- Bushing Type Required: SK Quick Detachable (QD) style
- Bore Capacity Range: 1/2 inch to 2-5/8 inches (depending on the chosen SK bushing)
Design and Use
- Hardened Teeth: The "H" suffix signifies heat-treated teeth, which are critical for increasing resistance to tooth deformation and abrasive wear in harsh settings.
- QD Style Component: Built as a Type B hub configuration. It securely mounts to an interchangeable SK bushing using three cap screws, creating a strong, slip-free compression grip on the shaft.
- Surface Protection: Usually manufactured with a black oxide finish to shield the steel from environmental moisture and premature rusting.
- Common Applications: Widely implemented in heavy-duty conveyor systems, industrial machinery drives, forestry tools, and agricultural gear box assemblies.
